- Size: 25
- Place of Origin: Linyi, Shandong
- Brand Name: Senmao
- Model Number: Sm-500
- Weight: 33000.000 kg
Model | (SM4*8RY15-500) |
Total pressure | 500TONS |
Board feeding direction | Transverse 2700mm size |
Layers | 15Layers |
Layer spacing | 70mm |
Hot press plate | Number of hot press plate: 16pcs |
Size:2700*1370*42mm | |
Material:Q235 | |
Cylinder for hot press machine | 2*ø360mm, 1*ø180mm |
Wuxi cylinder, solid steel | |
Seal: 5 rubber seals per pcs of cylinder | |
Stroke: 1050mm | |
Hydraulic system for hot press machine | Compression resistance: 25 Mpa |
Low pressure pump flowing: 250ml/r*1pcs | |
high pressure pump flowing: 10ml/r*1pcs | |
Power: 26kw(18.5KW 7.5KW) | |
Full automatic | |
Overall dimension | 3550mm*1370mm*4650mm |
